12V 70ah LiFePO4 battery home energy storage 12V lithium ion battery

 12V 70AH LiFePO4 battery Household energy storage 12v lithium ion battery CAS is a professional manufacturer engaging in research, development, production, marketing and service of lithium ion battery cell, battery pack and battery management system. Lithium LiFePO4 is the major product. Standard battery pac

Featured Products

 12V 70AH LiFePO4 battery Household energy storage 12v lithium ion battery

CAS is a professional manufacturer engaging in research, development, production, marketing and service of lithium ion battery cell, battery pack and battery management system.

Lithium LiFePO4 is the major product. Standard battery pack from 12V-92V, 5AH-800AH, which can be used in electric vehicle, E-bike, UPS, energy storage system, telecommunication base station, E-scooter, E-tools, unmanned airplane, golf cart, fork lift, cleaning car, electric wheelchair, etc.


1, Product Specification

Nominal Voltage12.8V
Nominal Capacity(at 0.5C, 25 degC)70Ah
Min. Capacity (at 0.5C, 25 degC)70Ah
Length307±1mm
Width168±1mm
Height208±1mm
Net Weight10Kg
Charge MethodCC-CV
Max. Charge Voltage14.6V
Continuous Charge CurrentMax. 70A
Charge Temperature0ºC~45ºC
Continuous Discharge CurrentMax. 70A
Peak Instant Discharge Current(10 Seconds)120A
Discharge Cut-off Voltage10.0V
Discharge Temperature-20ºC~65ºC
Storage Temperature-20ºC~45ºC
Self Discharge (Stored at 50% SOC)<= 3%/month




2. Applications
1. Large-scale electric vehicles: Electric bus, electric car, E-Tour Car
2. Light electric car: E-bike, electric scooter, e-motor, electric golf car, forklift, cleanness car, electric wheelchairs
3. E-tool: Electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment
Usable for more than 4, 000 charge-discharge cycles
> 4 times than lead acid batter
> 2 times than li ion battery

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


3. Excellent performance
1. Safety: Safest Li-ion battery, CE UL approved, built-in protection circuit board (BMS), no fire, no explosion
2. Clean and Green energy, no toxic material contained
3. Long life cycle, > 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect, highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~65 C
6. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-CD battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly



4. Product picture
12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery
12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


Assembly:

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery






12V  series standard battery pack:
ItemMax. Charge CurrentMax. Discharge CurrentPeak current   Size(MM) ±2Weight Package
12V 5AH5A5A10A 10S151*65*95 0.4KGPlastic case
12V 10AH 10A10A20A 10S151*98*98 1.28KGPlastic case
12V 20AH20A20A40A 10S181*76*167 2.56KGPlastic case
12V 25AH20A20A40A 10S196*131*1553.2KGPlastic case
12V 30AH30A30A60A 10S175*175*1183.84KGPlastic case
12V 35AH35A35A70A 10S196*131*1554.48KGPlastic case
12V40AH40A40A80A 10S197*165*1695.12KGPlastic case
12V50AH50A50A100A 10S197*165*1696.4KGPlastic case
12V75AH  75A 75A200A 10S260*169*2087.04KGPlastic case
12V80AH80A80A200A 10S307*168*2087.68KGPlastic case
12V100AH  100A100A200A 10S329*172*21412.8KGPlastic case
12V200AH100A100A200A 10S525*270*22025.6KGPlastic case
12V300AH100A100A300A 10S525*270*22038.4KGPlastic case


Workshop:

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery

Safety:
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery



Packaging & Shipping:

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery


WHY CHOOSE US ?

1.Experience--More than 12 years Specialized in lithium battery
2.Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
3. Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
4. Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
5. Fresh battery-- All battery is fresh Production

12V 70ah LiFePO4 Battery Household Energy Storage 12V Lithium Ion Battery
