Prouduct Description
Features of LiFePO4 Battery
1,Longer Cycle Life:Offers up to 20times longer life and five times longer fioat life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
2,Lighter Weight:About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
3,Higher Power:Delivers twice power of lead acid battery,even high discharging rate,while maintaining high energy capacity.
4,wider Temperature Range:-20ºC-60ºC.
5,Superior Safety:Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact,overcharging or short circuit situation.
6,Increased Flexibility:Modular design enables deployment of up to four batteries in series and up to batteries in parallel.
| Electrical Characteristics | Nominal Voltage | 12.8v |
| Nominal Capacity | 20Ah | |
| Energy | 256Wh | |
| Internal Resistance | ≤80mΩ | |
| Cycle Life | >3000 cycles @ 1C 100% DOD | |
| Months Self Discharge | <3% | |
| Effciency of Charge | 100%@0.5C | |
| Effciency of Discharge | 96-99%@1C | |
| Standard Charge | Charge Cut-off Voltage | 14.6±0.1V |
| Charge Mode | 0.2C to 14.6V,then 14.6V,charge current to 0.02C(CC/CV) | |
| Charge current | 4A | |
| Max charge current | 20A | |
| Standard Discharge | Continuous current | 4A |
| Max discharge current | 20A | |
| Discharge Cut-off Voltage | 10V | |
| Environmental | Charge Temperature | 0 ºC to 45 ºC (32F to 113F) @60±25% Relative Humidity |
| Discharging Temperature | -20 ºC to 80 ºC (-4F to 140F) @60±25% Relative Humidity | |
| Storage Temperature | 0 ºC to 40 ºC (32F to 104F) @60±25% Relative Humidity | |
| Mechanical | Plastic Case | Blue PVC |
| Dimension | 181*76*166mm | |
| Terminal | connector | |
| Weight | 2.75kg |
